X-LHBC240-270-310W40-50KHV-M

240W / 270W / 310W Selectable LED Linear High Bay

The MESLA X-LHBC240-270-310W40-50KHV-M Selectable LED Linear High Bay delivers high-performance, energy-efficient lighting for large commercial, industrial, warehouse, and high-ceiling applications.

Designed with a durable die-cast aluminum housing, this high bay combines a compact, clean design with selectable wattage and color temperature, giving contractors and facility managers the flexibility to adjust the fixture to the specific lighting requirements of each application.

With three selectable power levels — 240W, 270W, or 310W — and two selectable color temperatures — 4000K or 5000K — one fixture provides multiple lighting configurations while helping simplify inventory and installation.

Key Features

• Selectable Wattage: 240W / 270W / 310W
• Selectable CCT: 4000K / 5000K
• High Voltage: 277–480V
• High-Efficiency LED Technology: Up to 150 lm/W standard or up to 170 lm/W with the high-efficiency version
• 0–10V Dimming: Adjustable from 100% down to off
• Durable Die-Cast Aluminum Housing
• White Corrosion-Resistant Powder-Coated Finish
• 6kV L-N / 10kV L/N-PE Surge Protection
• CRI: >80
• UGR: <28
• 5-Year Warranty
• Optional Motion Sensor and Remote Controller
• Optional Zhaga Base
• Optional Emergency Battery Backup
• General and Aisle Optic Lens Options

Electrical Specifications

Input Voltage: 277–480V
Frequency: 50/60Hz
Wattage: 240W / 270W / 310W selectable
Dimming: 0–10V
Surge Protection: L-N 6kV / L/N-PE 10kV

Optical Specifications

The LHBC features a high-quality polycarbonate lens with a high-angle cut-off design to provide controlled illumination while helping reduce glare.

Color Temperature: 4000K / 5000K selectable
CRI: >80
UGR: <28
Optics: General Optic or Aisle Optic
Efficiency: Up to 150 lm/W standard
High-Efficiency Option: Up to 170 lm/W

Construction

The X-LHBC features a rugged die-cast aluminum housing designed for durability and effective heat dissipation. The white powder-coated finish provides a clean, professional appearance while helping protect the fixture against corrosion.

Optional Accessories

The X-LHBC can be configured with a range of control and emergency options:

• Motion Sensor
• Remote Controller
• Zhaga Base
• Emergency Battery Backup
• General Optic Lens
• Aisle Optic Lens

Operating Temperature

-13°F to 122°F (-25°C to 50°C)

Applications

The MESLA X-LHBC 240/270/310W Selectable LED Linear High Bay is ideal for:

• Warehouses
• Distribution Centers
• Manufacturing Facilities
• Industrial Buildings
• Storage Facilities
• Commercial Buildings
• Sports Facilities
• Gyms and Fitness Centers
• Workshops
• High-Ceiling Applications

Designed for Flexibility and Performance

The MESLA X-LHBC240-270-310W40-50KHV-M gives you three wattage options and two color temperatures in a single high-performance fixture. Whether you need maximum output for a large warehouse or a lower power setting for energy savings, the selectable design allows the fixture to be configured for the application.

240W • 270W • 310W | 4000K • 5000K | 277–480V

MESLA Lighting — High-Performance LED Solutions Built for Commercial and Industrial Applications.
